UV/VIS Photometric & UV/VIS Wavelength Absorbance Validation Plate


UV/VIS photometric and wavelength validation plate for microplate readers.

Add To Cart

Welcome to the home of Firefly's solid-state UV-VIS Spectrophotometer Calibration Standards.

This calibration plate includes the following well standards:


  • Photometric accuracy in the UV/VIS range (certified at 250, 280, 340, 360, 400, 465, 500, 546.1, 590 and 635nm)
  • Wavelength accuracy in the UV and VIS range (241.5-637.5nm)

Product Specs:

  • Tolerance for photometric accuracy filters: +/- 0.0022 au
  • Tolerance for wavelength accuracy filters: +/- 0.2nm
  • External dimensions of individual wells: 6.6mm per well
  • Total dimensions for 96 well plate: 85x125x12.5mm

Benefits of Firefly's Solid-State Well Plate Calibration Standards:

  • Highly accurate and consistent spectrophotometer calibration every time.
  • Never has to be replaced.
  • Never has to be recalibrated if handled and stored properly.
  • Scratch-resistant coating protects optical surfaces.
  • Can be used in any spectrophotometer (with standard 12.5 x 12.5 x 45.0 mm holder)
  • Surpasses NIST requirements and tolerances.
  • NIST-traceable and ISO compliant.
