Cylindrical Polarimeter Cells
Cells for use in polarimeters and spectrophotometers, which contain a cylindrically shaped sample chamber.
Type 32 Standard Cylindrical Polarimeter Cell with PTFE Stopper (Lightpaths: 1-20mm)
Type 32 Standard Cylindrical Polarimeter Cell with PTFE Stopper (Lightpaths: 1-20mm)
FireflySci's basic cylindrical polarimeter cell with a PTFE stopper for keeping the contents firmly secured.
Features of FireflySci Type 32 Cylindrical Polarimeter Cell:
Highly accurate results, only need to test sample once.
Premium quality: Firefly cuvettes are made with the best quality quartz and glass material available. Excellent transmission values.
Made by hand, ensuring high quality optical polishing with no defects.
Each cell goes through a rigorous inspection process before leaving our factory.
Fire-fused to ensure that cuvettes are robust and durable.
Comes in several different materials: (Optical Glass, UV Quartz, IR Quartz)
Lightpaths from 1-20mm available
Two windows optically polished.
Includes PTFE stopper.
Tapered inlet/outlet port: OD8mm x ID5mm at the opening
| Lightpath | Top | Outer Length | Outer Diameter | Outer Height | Chamber Length | Chamber Diameter | Capacity |
|---|---|---|---|---|---|---|---|
| 1mm | PTFE Stopper | 3.50mm | 22.0mm | 30.0mm | 1.0mm | 19.0mm | 0.280ml |
| 2mm | PTFE Stopper | 4.50mm | 22.0mm | 30.0mm | 2.0mm | 19.0mm | 0.560ml |
| 5mm | PTFE Stopper | 7.50mm | 22.0mm | 30.0mm | 5.0mm | 19.0mm | 1.400ml |
| 10mm | PTFE Stopper | 12.50mm | 22.0mm | 30.0mm | 10.0mm | 19.0mm | 2.800ml |
| 20mm | PTFE Stopper | 22.50mm | 22.0mm | 30.0mm | 20.0mm | 19.0mm | 5.600ml |
